Ideal for indoor or outdoor lighting, heat lamps, and various pool and spa equipment.
Easy to install two-wire design will fit into any standard single gang wall box.
| Model | Timing Range | Price |
|---|---|---|
| PM-15M | 0-15 minutes | $36.20 |
| PM-30M | 0-30 minutes | $41.70 |
| PM-60M | 0-60 minutes | $42.85 |
| PM-12H | 0-12 hours | $43.00 |
Specifications:
| Features | Description |
|---|---|
| Switch: | Single pole, single throw (SPST). Switch circuit is in an open position at the end of the timing cycle |
| Ratings: | 20 amps, 125 V.A.C., 1 H.P. 10 amps, 250 V.A.C. 10 amps, 277 V.A.C. 7 amps, 125 V.A.C., Tungsten |
| Operating Temperature Range: | 14 degree F. to 104 degree F -10 degree C. to 40 degree C |
| Storage Temperature: | -50 degree F. to 180 degree F -46 degree C. to 82 degree C |
| Cover Plate: | Brushed aluminum |
Additional Information
| Commercial Timer | PM-12H, PM-15M, PM-30M, PM-60M |
|---|
